Audio Technica 3000 Uhf 40 Channel Intelliscanning In Ear Monitor System with Ear Buds

You are looking at Audio Technica 3000 Uhf 40 Channel Intelliscanning In Ear Monitor System With Earbuds

Description:

3000 Series IEM

The Audio-Technica 3000 Series Wireless In-Ear Monitor System (ATW-3255) was designed to bring professional sound quality and features to all levels of performers and performance venues. System integrators for houses of worship, owners of live-performance venues and the musicians who play in them all tell us the same thing: They need an affordable, durable in-ear monitor system that is easy to use and, crucially, delivers high-quality sound with dependable RF.The 3000 Series Wireless IEM provides all that and more.

Specs:

Overall System

• Operating Frequencies: Band DF2: 470.125 to 607.875 MHz Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth/transmitting power due to local regulations.
• Minimum Frequency Step: 25 kHz
• Modulation Mode: FM
• Nominal/Peak Deviation: ±34 kHz nominal / ±45 kHz peak
• Frequency Response: 40 Hz to 14,100 Hz
• Stereo Separation: 75 dB
• Operating Range: 90 m (300′)
• Dynamic Range: >90 dB, A-weighted, typical
• Total Harmonic Distortion: <0.2% (at 1 kHz, +4dBu input)
• Maximum Simultaneous Use (recommended): 49 ch per bandFor assistance with multi-band operation or other frequency coordination issues, contact your local Audio-Technica dealer.

IEM Transmitter

• RF Output Power: High: 50 mW, Low: 10 mW (switchable) at 50 ohmsMay differ depending on the country or region in which you live.
• Input Connection: XLR-F type×2 (Pin1: GND, Pin2: Hot, Pin3: Cold)
• Maximum Input Level: XLR-F type: +24 dBu (at 0 dB sensitivity)
• Output Connection: 6.3 mm (1/4″) TRS×2 (Tip: Hot, Ring: Cold, Sleeve: Ground）
• Network: 100BASE-T
• Network Port: RJ-45
• Power Supply: 100 to 240 V AC (50/60 Hz) to 12V DC 1 A (center positive) switched mode external power supply
• Antenna Output: BNC-type, 50 ohms
• Dimensions: 210 mm (8.3″)×191 mm (7.5″)×43.4 mm (1.7″) (W×D×H)
• Weight: 1,100 g (39 oz)(without accessories)
• Included Accessories: AC adapter Rack-mount (large, small) Flexible UHF antenna

Receiver

• Receiving System: Antenna diversityAudio output cable performs as a secondary antenna to ensure stable RF performance.
• Image Rejection: >80 dB, typical
• RF Sensitivity: 20 dBuV at 60 dBA S/N ratio (50 ohms termination)
• Headphone Output Jack: 3.5 mm (1/8″) TRS stereo mini-jack
• Headphone Output: 40 mW (at 12 ohms)
• EQ: Low: 80 Hz / 160 Hz / 320 Hz / ±9 dB in 3 dB step High: 6 kHz / 8 kHz / 10 kHz / ±9 dB in 3 dB step
• Limiter: Selectable: -30dB to OFF (0 dB) in 6 dB steps
• Antenna Input: SMA type, 50 ohms
• Operating Temperature Range: -5℃ to +45℃ (23℉ to 113℉)Battery performance may be reduced at very low temperatures.
• Dimensions: 64 mm (2.5″)×23 mm (0.91″)×82 mm (3.2″) (W×D×H)
• Weight: 102 g (3.6 oz) (without batteries)
• Accessories Included: ATH-E40
• Battery Current/Life: 4 to 6 hours (alkaline); 5 to 7 hours (Ni-MH, 1900 mAh); 11 to 13 hours (Lithium)Depending on battery type, usage, volume level and environmental conditions.
• Battery Type: 3 V DC (two 1.5 V AA) (not included)
